40GBASE-SR4 40G Ethernet 850nm QSFP+ Transceiver Module

40GBASE-SR4

40G Ethernet 850nm QSFP+ Transceiver Module

Description

The QSFP+ (Quad Small Form-factor Pluggable Plus) is a new Multi-Source Agreement (MSA) for high speed application, such as 40Gbps, which provide four channels of data in one pluggable interface. Each channel is capable of transferring data at 10Gbps and supports a total of 40Gbps.
The 40Gbps QSFP+ transceiver is well suited for Infiniband and 40GBASE-SR4 / 40GBASE-LR4applications. It combines the higher density attractions of parallel modules with some of the key advantages normally associated with SFP+ based modules. It is intended for use short reach applications in switches, routers and data center equipment where it provides higher density and lower cost when compared with standard SFP+ modules.

Features

• ^{QSFP+ MSA, SFF-8436 compatible}
• ^{Four independently addressable transmit and receive channels}
• ^{Highly compact: savings of 60% on edge and board usage compared to four comparable SFP+ modules}
• ^{Electrically hot-pluggable}
• ^{XFP-like latch mechanism for ease-of-insertion}
• ^{Digital Diagnostics Monitoring Interface. allows customer management and monitoring of key modules parameters, analogous to SFP+}
• ^{Optical connectivity via industry standard MPO/MTP terminated fiber ribbon}

Applications

• High-speed interconnects within and between switches, routers and transport equipment
• Server-Server Clusters, Super-computing interconnections
• Proprietary backplanes
• Interconnects rack-to-rack, shelf-to-shelf, board-to-board, board-to-optical backplane
• 40GBASE-LR4 Ethernet links
• 10GBASE-SR applications
• 40GBASE-SR4 applications
• InfiniBand SDR, DDR and QDR applications

Specification:

Competitive Advantages:
<sup>1. Excellent quality and 3 years warranty
2. Competitive pricing
3. Full compatible
4. OEM/ODM Customized label
5. Keep stock,Fast delivery</sup>
